Specification Sheet
| pH Sensor | Parameter | pH/ORP |
| Body Type | ø12mm Glass Body | |
| Technology | Double Junction Combination Electrode | |
| Range | 0 to 14 pH | |
| Process Pressure | up to 10 Bar | |
| Process Temperature | up to 135 °C | |
| Liquid Junction | Ceramic / TEFLON / Pin Hole / Non-porous Polymeric Junction | |
| Temperature Compensation | PT100 / PT1000 | |
| Reference Electrode | Ag-AgCl | |
| Length | 120mm / 225mm / 325mm / 425mm | |
| Process Connection | PG 13.5 Rotating cap | |
| Special | Steam Sterilizable | |
| Application | Fermenters, Bio-reactors, Specialty Chemical, Pharmaceutical, Pure Water | |
| Parameter | pH/ORP | |
| Body Type | Ryton Body Moulded Electrode with Threaded Ends | |
| Technology | Double Junction Combination Electrode | |
| Range | 0 to 14 pH | |
| Process Pressure | up to 10 Bar | |
| Process Temperature | up to 140 °C | |
| Liquid Junction | TEFLON / Non-porous Polymeric Junction | |
| Temperature Compensation | PT100 / PT1000 | |
| Reference Electrode | Ag-AgCl | |
| Process Connection | 3/4" NPT / 1" NPT | |
| Application | Water treatment, Effluent treatment, Specialty chemical, Pharmaceutical | |
| pH Controller/Transmitter | Type | 2-Wire Intrinsically Safe pH Transmitter |
| Body | Cast Aluminium | |
| Safety | Ex[ia] Group IIA, IIB, IIC T6 | |
| Ingress Protection | IP 67 | |
| Communication Protocol | HART 7.0 | |
| Temperature Input | Automatic Compensation PT-100/PT-1000 | |
| Power Input | 12 – 36 VDC with maximum load 600Ω at 24 VDC | |
| Output | 4-20 mA DC, galvanically isolated output | |
| Mounting | Field Mounted on Wall or Pipe | |
| Type | pH Controller | |
| Body | Cast Aluminium | |
| Ingress Protection | IP 66 | |
| Display | Dual Display LED Backlit | |
| Analogue Output | 4-20 mA DC, galvanically isolated output | |
| Relay Output | 2 Output Relays | |
| Temperature Input | Automatic Compensation PT-100/PT-1000 | |
| Power Input | 24V DC / 230V AC | |
| Mounting | Field and Panel Mounted | |
